Technical Parameters
Part Number：M01C02479
Layer count: 1
Board thickness：2.0mm
Dimension：209*148mm
Raw material：copper base
Copper thickness on the board surface：≥70um
Copper thickness in the hole barrel：25um
Min.line width/space：0.22mm
Minimum hole diameter：0.4mm
Surface finishing：immersion gold≥1u"
Application：power supply
